Protectli Vault FW4B

313,36 448,70  (ex. VAT)


The Vault is an open-source firmware ready firewall manufactured by Protectli, focused on network appliance and firewalls. One of the main advantages of this platform is fanless design allowing for silent work and small dimensions together with running on approximately 10 Watts under moderate load, 18W max. With an Open Source solution, you can choose which Operating System will run your network, with full control over the configuration!

Datasheet: link
Knowledge Base: link

SKU: N/A Category:

Additional information

Weight 1,1 kg
Order Processing Time

The preparation of the equipment for shipment can take up to 6 working days.

Delivery time

Poland – up to 2 working days, European Union – up to 6 working days, Worldwide – Express up to 8 working days, Economic up to 30 working days


The Vault is a small form factor PC built for use as a firewall / router. The FW4B is based on a 4 network port design that leverages a low power, but versatile Intel Celeron J3160 CPU. This CPU supports AES-NI, Intel’s Hardware Acceleration for Encryption. The Vault uses standard Intel components (including Intel network ports) which results in compatibility with a variety of operating systems, including a number of open source firewall projects. The Vault has no moving parts, which increases it's durability in less than ideal environments. Its whole aluminum enclosure is a giant heat sink, keeping the CPU cool with fanless design!


Kit includes

  • Vault platform
  • Optional RAM / Storage / WiFi
  • BIOS: UEFI stock | Dasharo
  • OS (with storage only): Debian 11 | Ubuntu 20.04 | FreeBSD 13
  • Universal Power Supply, VESA mount kit, Serial (RS232) to network (RJ45) adapter cable, Quick Start Guide


Specification FW4B (4 ports)
Processor Intel Celeron® J3160 Quad Core at 1.6 GHz (Turbo 2.24 GHz)
Network 4 Intel® Gigabit i210-AT Ethernet NIC ports
Graphics Intel Clear Video HD Technology
Audio Intel HD Audio Technology
Storage 128GB mSATA SSD
I/O ports 1x USB 3.0, 1x USB 2.0, 1x RJ-45 COM, 1x VGA
Instruction set AES-NI support
WiFi 802.11 b/g/n/ 2.4GHz Module (installed)
Dimensions 115mm × 107.5mm × 39mm
Cooling Radiators (fanless and silent)
Mount kit Included VESA mount kit
