Dasharo: Enterprise Gigabyte MZ33-AR1

Dasharo: Enterprise Gigabyte MZ33-AR1

Price range: 9100,00 € through 9150,00 € (ex. VAT)

Overview

The Enterprise Gigabyte MZ33-AR1 with Dasharo Pro Package for Servers is a validated 2U server platform for organizations that need a reliable AMD EPYC-based foundation with open-source firmware support. Built around the GIGABYTE MZ33-AR1 server motherboard, it combines a single-socket AMD EPYC 9005/9004 platform with DDR5 ECC memory, PCIe Gen5 expansion, NVMe storage support, dual 10GbE networking, TPM 2.0, and remote platform management.

This configuration is assembled from components validated with Dasharo, including a Supermicro 2U chassis, hot-swap NVMe storage, server-class cooling and power delivery, and the GIGABYTE CTM012 TPM module. It is intended for customers who need a serviceable and supportable server system rather than a generic off-the-shelf build.

The platform is well suited for virtualization, private cloud infrastructure, secure build environments, CI/CD systems, storage nodes, network services, and firmware development or validation labs where platform transparency and long-term maintainability are important.

The system is delivered with the Dasharo Pro Package for Servers, providing access to Dasharo open-source firmware updates and professional support. Available firmware configurations include coreboot+UEFI and coreboot+LinuxBoot, allowing the customer to choose the boot stack that best matches their deployment model.

Specifications

Category Product name
Motherboard GIGABYTE MZ33-AR1
CPU AMD EPYC 9015 (8 / 16) 3.6GHz (up to 4.1GHz) Socket SP5
RAM Micron RDIMM 32GB DDR5 1Rx4 6400MHz PC5-51200 ECC Registered
Storage (NVMe) Intel P4510 U.2 1TB Entry NVMe PCIe 3.0 x4 Hot Swap
NVMe mounting adapter Supermicro MCP-220-00116-0B
CPU Cooling Supermicro SNK-P0083AP4
TPM GIGABYTE CTM012
Chassis (2U) Supermicro CSE-826BAC12-R1K23LPB
Power Distribution Board (PDB) Supermicro PDB-PT826-S4824
EPS Power Adapter Akyga AK-CA-08 EPS
ATX Power Adapter Akyga AK-CA-09
NVMe cable (0.5m) CAB-MCIOi8-8654i8

This configuration is based exclusively on components that have been internally validated and tested with Dasharo. Using the recommended setup ensures full firmware compatibility, stable operation, and access to official Dasharo support. Functionality outside the validated configuration cannot be guaranteed.

Key Features

  • Enterprise-grade 2U server platform based on the GIGABYTE MZ33-AR1 motherboard
  • Validated AMD EPYC™ 9015 configuration with support for AMD EPYC™ 9005/9004 processors
  • 12-channel DDR5 RDIMM architecture with 24 DIMM slots
  • PCIe Gen5 expansion with 4x PCIe Gen5 x16 slots
  • Flexible NVMe, SATA, and M.2 PCIe Gen4 storage expansion
  • Dual 10GbE LAN, dedicated management LAN, and ASPEED® AST2600 BMC remote management
  • TPM 2.0 support with Dasharo open-source firmware
  • Available firmware configurations: coreboot+UEFI or coreboot+LinuxBoot

By combining an AMD EPYC server platform with Dasharo open-source firmware, this system gives customers greater control over boot behavior, firmware update strategy, and platform lifecycle. The validated 2U configuration reduces integration risk compared to a self-assembled server build, while the Dasharo Pro Package provides access to firmware updates and professional support.

Documentation

You support open-source firmware and Dasharo distribution by buying the hardware and package.

Tamper-proof sealing option:
To avoid any intentional interference during transit, the package can be secured with seals. Photos of the seals will be provided via email for verification upon delivery. Additionally, the BIOS will be secured with a password, which will also be sent via email.

By purchasing this product, you confirm that you have read and accepted the Dasharo Terms of Service.

x
SKU: N/A Category: Tags: , , ,

Additional information

Weight 12 kg
Order Processing Time

Due to limited availability, we cannot guarantee immediate stock of this motherboard. In some cases, additional lead time of up to 3 weeks may be required.

Description

Value Proposition

This configuration is tailored for customers requiring firmware transparency, validated hardware integration, PCIe Gen5 expansion, remote manageability, and long-term platform maintainability. It is particularly suited for:

  • Virtualization and private cloud infrastructure
  • Secure build servers and CI/CD infrastructure
  • Firmware development, testing, and validation labs
  • Software-defined storage and NVMe/SATA storage nodes
  • Network services, lab infrastructure, and edge or datacenter appliances

    • By combining an AMD EPYC server platform with Dasharo open-source firmware, this system gives customers greater control over boot behavior, firmware update strategy, and platform lifecycle. The validated 2U configuration reduces integration risk compared to a self-assembled server build, while the Dasharo Pro Package provides access to firmware updates and professional support.

    Dasharo Pro Package for Servers

    The Dasharo Pro Package for Servers grants access to the firmware updates for the Server line of devices supported by Dasharo.
    Firmware configuration is selected above using the Dasharo Pro Package option selector.

    Available firmware configurations:

  • coreboot + UEFI

  • coreboot + LinuxBoot

    • Important notes about the LinuxBoot firmware option:

  • Provides a lightweight Linux-based boot environment focused on simplicity and transparency
  • Does not include the additional security and verification features available in Heads
  • Firmware configuration options are limited compared to the default coreboot + EDK II firmware
  • Supports GNU/Linux operating systems only

    • The personalized digital package includes:

  • Firmware Updates: Access to the latest binary releases of Dasharo open-source firmware distribution for supported Server platforms. Firmware updates focus on enhanced privacy, security, performance, and compatibility.
  • Newsletter Subscription: a detailed overview of release changes, insights into enhancements, and convenient access to direct links for binary files.
  • Premier Support: Access to the Dasharo Premier Support invite-only live chat channel in the Matrix network, facilitating direct engagement with the Dasharo Team and fellow customers with personalized and priority assistance.
  • Community Involvement: Inclusion in the Dasharo community for sharing thoughts, proposing enhancements, and reporting issues through public channels. Active community participation will significantly impact the future development of Dasharo specifically for these devices.
  • Influence on roadmap: Insider visibility and the ability to influence the Dasharo features roadmap.

    • Specifications

    Model Name MZ33-AR1
    Form Factor (WxD, mm) E-ATX
    304.8 x 330.2
    CPU AMD EPYC™ 9005 Series Processors
    AMD EPYC™ 9004 Series Processors
    Single processor, cTDP up to 500W
    Socket 1 x LGA 6096
    Socket SP5
    Chipset System on Chip
    Memory 24 x DIMM slots
    DDR5 memory supported
    12-Channel memory per processor

    AMD EPYC™ 9005:
    RDIMM: Up to 5200 MT/s (1DPC)
    RDIMM: Up to 4400 MT/s (1R 2DPC), 4000 MT/s (2R 2DPC)

    AMD EPYC™ 9004:
    RDIMM: Up to 4800 MT/s (1DPC), 3600 MT/s (2DPC)
    LAN 2 x 10Gb/s LAN (1 x Broadcom® BCM57416)
    - Support NCSI function
    1 x 10/100/1000 Mbps Management LAN
    Video Integrated in ASPEED® AST2600
    - 1 x VGA port
    Audio N/A
    Storage Interface MCIO:
    2 x MCIO 8i for 4 x Gen5 NVMe or 16 x SATA
    3 x MCIO 8i for 6 x Gen5 NVMe
    1 x MCIO 8i for 2 x Gen4 NVMe

    M.2:
    1 x M.2 (2280/22110), PCIe Gen4 x4
    RAID N/A
    PCIe Expansion Slots Slot_7: PCIe x16 (Gen5 x16)
    Slot_6: PCIe x16 (Gen5 x16)
    Slot_4: PCIe x16 (Gen5 x16)
    Slot_3: PCIe x16 (Gen5 x16)

    2 x MCIO 8i (PCIe Gen5 x8 or SATA)
    3 x MCIO 8i (PCIe Gen5 x8)
    1 x MCIO 8i (PCIe Gen4 x8)
    Internal I/O 1 x 24-pin ATX main power connector
    2 x 8-pin ATX 12V power connectors
    1 x 6-pin ATX 12V power connector
    1 x CPU fan header
    5 x System fan headers
    1 x USB 3.2 Gen1 x2 header
    1 x USB 2.0 header
    1 x M.2 slot
    6 x MCIO 8i connectors
    1 x Front panel header
    1 x Backplane board header
    1 x PMBus connector
    1 x IPMB connector
    1 x TPM header
    Rear I/O 2 x USB 3.2 Gen1 ports (Type-A)
    1 x VGA port
    1 x COM port
    2 x RJ45 ports
    1 x MLAN port
    1 x ID button with LED
    Security Modules 1 x TPM header with SPI interface
    Operating Properties Operating temperature: 10°C to 40°C
    Operating humidity: 8% to 80% (non-condensing)
    Non-operating temperature: -40°C to 60°C
    Non-operating humidity: 20% to 95% (non-condensing)

    Disclaimer

    Due to necessary modifications to the board, the standard warranty does not apply to this product.
    3mdeb guarantees proper operation of the platform for two years under the following conditions:

    1. The hardware used only the Certified Dasharo firmware version. If other firmware is or has been installed, the warranty is void.
    2. There are no signs of customer interference with the platform or firmware.
    3. The customer delivers a 3mdeb platform at their own expense for analysis and possible repair, together with a detailed description of the problem.

    When all the above conditions are met, 3mdeb will try to restore the original configuration and re-flash Dasharo. The platform will then be returned to the customer at 3mdeb’s expense, provided that conditions 1 and 2 have not been breached.
    If the above conditions are not met, or in the event of culpable action by the customer, warranty repair is not provided, and the warranty for the item is void.
